  5. 8 PORT GIGABIT ETHERNET SWITCH POE UNMANAGED INDUSTRIAL RUGGED
By StarTech.com

8 PORT GIGABIT ETHERNET SWITCH POE UNMANAGED INDUSTRIAL RUGGED

$437.27
$455.99 $437.27
-$18.72
Shipping calculated at checkout.
Brand: StarTech.com
Availability: Low stock: 7 left
SKU: 8NT067
Collections:
$437.27
$455.99 $437.27
JuniperQFX5120-48Y AIRFLOW IN RED AC PSUS FANS SHIPS W/ BASE S/W
QFX5120-48Y AIRFLOW IN RED AC PSUS FANS SHIPS W/ BASE S/W
ARUBA ION 1430 26G 2SFP SW US EN PL-I5
HPEARUBA ION 1430 26G 2SFP SW US EN PL-I5
StarTech.com Industrial 8 Port Gigabit PoE Switch 30W - Power Over Ethernet Switch - GbE POE+ Network Switch - Unmanaged - IP-30 - 8 Port Gigabit PoE switch 30W PSE power per port to devices w/GbE on Cat5e/6 - Power over Ethernet Network IEEE 802.3af/at |10/100/1000 Mbps |Unmanaged |Alarm Relay |DIN/Wall Mount |Redundant Power Input IP-30 /Industrial Hardened -40C to 75C temp

Technical Specifications:
  • Product Type:Ethernet Switch
  • Power Source:PoE+
  • Layer Supported:2
  • Form Factor:DIN Rail Mountable
  • Form Factor:Wall Mountable
  • Power Consumption:206 W
  • Brand Name:StarTech.com
  • Plug/Connector Type:Terminal Block
  • Manageable:No
  • Ethernet Technology:Gigabit Ethernet
  • Media Type Supported:Twisted Pair
  • Total Number of Network Ports:8
  • PoE (RJ-45) Port:Yes
  • Product Type:Ethernet Switch
  • Manufacturer Part Number:IESC1G80UP
  • Manufacturer Website Address:http://www.startech.com
  • Manufacturer:StarTech.com
  • Product Name:Ethernet Switch
  • Brand Name:StarTech.com
  • Marketing Information:

    This industrial 8 port gigabit PoE switch features 30W of power and is designed to be installed in harsh environments and supports up to a total of 200W power outputs. Includes hardware for DIN rail or wall mounting.

    For Demanding Environments Where No Fiber Connections Are Required

    Using Cat 5e (or higher rated) Ethernet cabling, this Ethernet switch Provides up to 30W of PSE power per PoE port (PSE) to IEEE 802.3af (PoE / Type 1) and IEEE 802.3at (PoE+ / Type 2) PD devices like:

    • Cameras
    • Sensors
    • Wi-Fi Access Points

    High total power budget with high PoE port count at a maximum of 30 watts per port, up to 200 watts max. Power provided in order of device connection; max 6 802.3at (30W) devices (180W total) at any time.

    Truly Industrial for Devices That Must Function Under Harsh Conditions

    Industrial features include:

    • Operating Temperature Range: -40 C to 75 C
    • IP-30 rated housing
    • Vibration, shock, and free-fall standard testing

    This Ethernet switch supports additional features such as redundant power inputs, 2kV surge protection on RJ45 ports, and an MTBF of 500,000+ hrs (Telcordia/Bellcore) at 50°C, for long-term reliability.

    More from the Manufacturer

  • Network (RJ-45):Yes
  • Total Number of Network Ports:8
  • Port/Expansion Slot Details:8 x Gigabit Ethernet PoE+
  • Manageable:No
  • Network Technology:10/100/1000Base-T
  • Ethernet Technology:Gigabit Ethernet
  • Media Type Supported:Twisted Pair
  • Package Contents:
    • Ethernet Switch
    • Mounting Hardware Kit
    • Quick-Start Guide
    • Terminal Block
  • Country of Origin:Taiwan
  • Environmentally Friendly:Yes
  • Environmental Certification:RoHS
  • Environmental Certification:WEEE
  • Layer Supported:2
  • Weight (Approximate):1.18 lb
  • Form Factor:DIN Rail Mountable
  • Form Factor:Wall Mountable
  • Length:5.6"
  • Height:1.6"
  • Width:4.1"
  • Product Material:Steel
  • Power Source:PoE+
  • Power Consumption:206 W
  • Plug/Connector Type:Terminal Block
  • PoE (RJ-45) Port:Yes
  • PoE Budget:200 W
